Description
- The Edwards 55 Ton Ironworker is well suited to fit the needs of any fab shop, large or small. Standard features include a Punch Assembly with Pedestal Die Table, Flat Bar Shear, Angle Shear and a universal open tooling station designed to accept optional Tooling Accessories.
- The optional Hydraulic Accessory Pack allows your Ironworker to act as a power source to our expanding line of innovative Hydraulic Accessory Tools, such as the 10 Ton Tube/Pipe Bender, 20 Ton Shop Press and 40 Ton Shop Press.
- Four Available Workstations
- Universal Open Tooling Station
- Electric Stroke Control
- ANSI B11.5-1988R(02) Compliant
- ETL/UL Approved Controls
- MADE IN THE USA
- **MORE VOLTAGES AND OPTIONS AVAILABLE – PLEASE CONTACT US FOR MORE INFORMATION**
SPECIFICATIONS:
|
PUNCH
|
Maximum Capacity (in.)
|
1-1/16″ Dia. in 5/8″ A36
(65,000 PSI Tensile) |
|
|
Rating
|
55 Tons
|
||
|
Throat Depth (in.)
|
7-1/2
|
||
|
Open Height (in.)
|
8-1/8
|
||
|
Shut Height (in.)
|
6-7/8
|
||
|
Stroke (in.)
|
1-1/4
|
||
|
Work Height (in.)
|
36-9/16
|
||
|
FLAT BAR SHEAR
|
Max. Capacity (in.)
|
3/8 x 14
1/2 x 12 3/4 x 4 |
|
|
Max. Round Capacity (in.)
|
7/8
|
||
|
Max. Square Capacity (in.)
|
7/8
|
||
|
Work Height (in.)
|
34-1/2
|
||
|
ANGLE SHEAR
|
Max. Size (in.)
|
4 x 4 x 1/4 or 3 x 3 x 3/8
|
|
|
Work Height (in.)
|
39-7/8
|
||
|
OPTIONAL
COPER NOTCHER |
Max. Capacity (in.)
|
2-1/2″ x 4″ x 5/16″
|
|
|
Work Height (in.)
|
39-1/2
|
||
|
OPEN STATION SPECIFICATIONS
|
Troat Depth (in.)
|
11-3/16
|
|
|
Open Height (in.)
|
8-1/8
|
||
|
Shut Height (in.)
|
6-7/8
|
||
|
Stroke (in.)
|
1-1/4
|
||
|
Work Height (in.)
|
34-1/2
|
||
|
DIMENSIONS
|
Height (in.)
|
55-1/4
|
|
|
Width (in.)
|
44-3/8
|
||
|
Depth (in.)
|
36-1/8
|
||
|
Shipping Weight
|
2,480 lbs.
|
||
|
GENERAL SPECIFICATIONS
|
Electric Motor
|
Standard
|
5 HP, 3 Ph, 208V or 230V, 1725 RPM 14A
|
|
Optional
|
5 HP 3~ 460V, 1725 RPM 7 A
5 HP 3~ 575V, 1725 RPM 6 A 5 HP 1~ 230V, 1725 RPM 23 A |
||
|
Hydraulic Pump Size (GPM)
|
3-1/2 – single stage
|
||
|
Valve Pressure (PSI)
|
2,500
|
||
|
Reservoir (gallons)
|
7
|
||
|
Cylinder (in.)
|
2-1/2 ram
|
||
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
OPTIONAL ITEMS:
General Productivity Pack:
- Increase you Punching Efficiency and Accuracy
- AC2200 General Productivity Pack for 40TC – 100 IW
- AC2250 General Productivity Pack for 100T DLX & 120T IW
- FLEXIBILITY
- Contains Punches and Dies to produce the following size round holes: 3/16″. 5/16″, 7/16″, 1/2″, 9/16″, 5/8″, 11/16″, 13/16″, 15/16″, and 1-1/16″
- The Back Gauge utilizes a positive stop attachment that is fitted to the back of the Ironworker ensuing accurate shearing out to 48″
- PRODUCTIVITY
- Punch and Die Storage Tray easily mounts to either side of the output shoot
- The 48″ Back Gauge speeds up production on repeatable cuts by providing an adjustable stop for the flat bar shear and angle shear.
- The Fabricator’s protractor increase accuracy on the punch and flat bar shear workstations by guiding your work piece and is gauged at 15° increments through 180° featuring a straight edge and reversible design
- A Gauging table kit includes adjustable fences and handles quickly and easily guide your material for perfect repeatable actions
- SAFETY
- Punch diameter must meet or exceed the thickness of your material
- Super bright LED light with M12 connections has a powerful magnetic base allowing users to attach the light to any Ironworker surface and move as needed.
- PERFORMANCE
- Made of durable steel for long life
- Long lasting averages between 3,000 and 5,000 impacts
|
PART #
|
ITEM
|
|
ED9-HAT001
|
Portable Power Unit 1 Phase, 230 Volt
|
|
ED9-HAT002
|
Portable Power Unit 3 Phase, 230 Volt
|
|
ED9-HAT003
|
Portable Power Unit 3 Phase, 380 Volt 50HZ
|
|
ED9-HAT004
|
Portable Power Unit 3 Phase, 460 Volt
|
|
ED9-HAT005
|
Portable Power Unit 3 Phase, 575 Volt
|
|
ED9-HAT006
|
Portable Power Unit 3 Phase, 208 Volt
|
| OPTIONAL ATTACHMENTS – PRESS BRAKE TOOLING |
|
PART #
|
ITEM
|
|
ED9-PRB12
|
Press Brake Tooling 12″ Press Brake
|
| OPTIONAL ATTACHMENTS – ACCESSORY MACHINES |
|
PART #
|
ITEM
|
|
ED9-HAT1000
|
10 Ton Tube/Pipe Bender
|
|
ED9-HAT5000
|
Radius Roller
|
OPTIONAL ATTACHMENTS AND ACCESSORIES AVAILABLE – CONTACT FOR DETAILS
