Description
- Cut Gypsum the Easy Way
System Includes:
-
- Cutting cartridge system with an interchangeable orientation for crosscuts and ripcuts
- Specialized Cartridges utilizing Standard Utility Knife Blades
- Measuring Scales in Feet & Inches
- Freestanding machine
- Flip Stops included for repetitious cutting
- 8′ Quick Stop Gauge
- Mid-Way Fence for cutting smaller, and narrower panels at waist level
- Heavy-duty aluminum material rollers for loading panels into the frame
Customer Setup will be required to attach two main sections of the frame, a five foot section connecting to the main 10′ frame. Professional Setup is available
SPECIFICATIONS:
Max. Crosscut: 64 in.
Max. Depth of Blade: .5 in.
Max. Rip Cut: Unlimited
Cut Accuracy: 1/32 in.
Frame Length: 15 ft.
Machine Weight: 298 lbs.
Machine Footprint: 15 ft x 3 ft = 45 sq ft.
*Please Note: Customer Setup will be required to attach two main sections of the frame (5′ section’s connection to the main 10′ frame and align according to the floor underneath the machine. Professional Setup is available
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
OPTIONAL ITEMS – CALL FOR PRICE:
*Contact us for full list of optional accessories
