Description
- XP = XTRA PRODUCTION
- Our XP models are made and designed with production in mind. These models are efficient with an equipped 1.5HP Baldor motor, 2 stage gear pump that produces 26 stokes per minute. This XP model comes standard with a plethora of tooling and accessories designed for high-output production.
- We ensure the highest quality standards, souring 100 percent of our components in the
USA. Quality you can trust, and backed industry leading 3 year warranty. - You can find our METALpro Ironworkers with one of our 100+ distributors across the US. With 30 years of dedicated service to this industry we have developed a strong dealer network dedicated to taking care of our customers! Choose METALpro!
- APPLICATIONS – All in one ‘fabrication shop’ with capabilities in:
- Punching
- Forming
- Shearing
- Pressing
- Notching
- Pipe notching
- Bending
- *Rated on 65,000 PSI Tensile
- **NOTCHERS AND OTHER CUSTOM TOOLING SOLD SEPERATELY
- Made in the USA
STANDARD FEATURES:
- HI-LO 2 stage gear pump, 1.5HP Baldor Motor
- Punch capacity of 45 tons
- Power cavity with 3-in-1 8 inch shear
- 12 inch brake with back stop and guide table
- 8 piece punch and die set (standard bolt hole sizes)
- Wheel kit for maneuverability
- Stroke control kit with microadjust
- Punch and shear station guide tables
- Built in slug catcher
- Guarding complies with ANSI B11-8 standards
- 3 year warranty
SPECIFICATIONS:
|
MODEL
|
MP4500XP
|
|
|
SPEED
|
Strokes per minute
|
26
|
|
Motor
|
110V AC single phase,
1.5 HP, 2 Stage Pump |
|
|
Capacity
|
45 Tons
|
|
|
Throat Depth
|
3-3/4″
|
|
|
Punch
|
45 ton max capacity
|
|
|
SHEAR
|
Flat bar
|
up to 1/2″
|
|
Angle
|
1/4″ x 4″ x 4″
|
|
|
Rod
|
3/4″
|
|
|
Square
|
5/8″
|
|
|
Hydraulics
|
2900 PSI
|
|
|
Oil capacity
|
1.5 US gallons
|
|
|
ACCESSORIES (Included)
|
Brake
|
12 inch brake w/ back stop
and front guide table |
|
Limit Switch Kit
|
stroke control with microadjust
|
|
|
Guide Plates
|
punch station plate and
shear shelf extension |
|
|
Slug Catcher
|
holds hundreds of slugs
|
|
|
Wheel kit
|
locking casters
|
|
|
Shear back stop
|
adjustable shear back stop for repeat cuts
|
|
|
Punch and die set
|
8 piece PD set
(standard bolt hole sizes) |
|
|
FRAME DIMENSIONS
|
Width
|
24″
|
|
Height
|
59″
|
|
|
Length
|
36-1/2″
|
|
|
Weight
|
800 lbs.
|
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 3 YEAR
