Description
- DURABILITY:
- Heavy Cast Iron Bases
- Oversized motor shafts, heavy retainer plates and massive lock nuts
- SAFETY:
- CSA/US: Following strict guidelines and electrical requirements, these Industrial Buffers are CSA/US listed.
- Safety switches with removable key on 8 and 10″ as well as magnetic interlocking switch on 12″ model.
- EASE OF USE:
- Three Horsepower options allow you finish your delicate parts or your large castings.
- The wide range of spacer options allow you to run a huge variety of finishing wheels.
SPECIFICATIONS:
Motor: 2HP, 1Ph
Prewired: 230V
Amperage Draw @ 115V 1Ph: 12
Wheel Speed (RPM): 1,800
Shaft Diameter (in.): 1-1/4
Shaft Length (in.) Per Side: 9-3/4
Wheel Diameter (in.): 12
Spacer Sizes (in.) (Two of Each): 1/2, 1, 2, 3-1/8
Overall Dimensions (L x W x H / in.): 35-7/8″ x 9-11/16″ x 11-7/8″
Net Weight (lbs.): 86
Gross Weight (lbs.): 97
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 2 YEAR
OPTIONAL ITEMS:
JT9-578405: 10″ AND 12″ BUFFER DUST SHROUD
JT9-414800: JDCS-505, METAL DUST COLLECTOR STAND 115V
JT9-578172: IBG-STAND (8″, 10″ AND 12″)
JT9-578173: DBG-STAND (8″, 10″, AND 12″)
JT9-578100: DBG-LAMP, 3W LED LAMP FOR IBG-8″, 10″, 12″ BUFFERS
