Description
- Our PRB-75H Angle Iron Benders aka profile bending machines are fully equipped with a 3″ die set to roll metal square tube into rings. These roll benders are the perfect solution for any fabrication shop looking to speed up the manual process. These metal roller benders are popular amongst the metal fence manufacturing, green house manufacturing, roll cage fab shops, and welding fab shops.
- ISO 9001 certified
- Hydraulic top roller positioning with digital readout
- Max capacity: 4” tube and 3-1/2” pipe
- Heavy Duty 5-1/2HP AC main motor
- Heavy welded all steel construction
- Quiet compact hydraulic system
- Custom-made rollers are available per request, such as steel, nylon, etc.
- One year industrial warranty for parts
STANDARD EQUIPMENT:
- One set of universal combination rollers can do most works except pipes & round tubes (will need special dies)
- Foot pedal
SPECIFICATIONS:
Dia. of roller: 8-1/2 in.
Dia. of roller shaft:3 inch (75mm)
Motor: 5-1/2 HP, 220V/440V, 3 Phase
Roller Speed: 16 rpm
Oil Capacity: 28L = 8 Gal
Dimensions: 51 x 45 x 72
Weight (with top roller hydraulic positioning): 2,450 lbs.
OPTIONAL ITEMS – CALL FOR PRICE:
Optional roller sets for pipe and round tubing, any size, one set (3-rolls) – call for pricing
Optional anti-twisting attachment – call for pricing
34T-PRB-75H: ROLL SET FOR 3/4 INCH TUBING FOR GMC PRB-75H
1T-PRB-75H: ROLL SET FOR 1 INCH TUBING FOR GMC PRB-75H
114T-PRB-75H: ROLL SET FOR 1-1/4 INCH TUBING FOR GMC PRB-75H
112T-PRB-75H: ROLL SET FOR 1-1/2 INCH TUBING FOR GMC PRB-75H
2T-PRB-75H: ROLL SET FOR 2 INCH TUBING FOR GMC PRB-75H
212T-PRB-75H: ROLL SET FOR 2-1/2 INCH TUBING FOR GMC PRB-75H
3T-PRB-75H: ROLL SET FOR 3 INCH TUBING FOR GMC PRB-75H
34P-PRB-75H: ROLL SET FOR 3/4 INCH PIPE FOR GMC PRB-75H
1P-PRB-75H: ROLL SET FOR 1 INCH PIPE FOR GMC PRB-75H
114P-PRB-75H: ROLL SET FOR 1-1/4 INCH PIPE FOR GMC PRB-75H
112P-PRB-75H: ROLL SET FOR 1-1/2 INCH PIPE FOR GMC PRB-75H
2P-PRB-75H: ROLL SET FOR 2 INCH PIPE FOR GMC PRB-75H
212P-PRB-75H: ROLL SET FOR 2-1/2 INCH PIPE FOR GMC PRB-75H
3P-PRB-75H: ROLL SET FOR 3 INCH PIPE FOR GMC PRB-75H
Specifications are subject to change without notice.
NOTE: Data is provided by the manufacturer.
WARRANTY: 1 YEAR – Parts
